DH Robotics PGE-8 Parallelgreifer
DH Robotics PGE-8 Parallelgreifer
DH Robotics PGE-8 Parallelgreifer
Gripping force (per jaw): 2~8 N
Stroke (both sides): 14 mm
Mechanical specifications
Force repeatability: ± 0.3 N
Position repeatability (gripping): ± 0.02 mm
Finger backlash: 0.1mm or less per jaw
Opening/closing time: 0.2 s/0.2 s
Driving method: Rack and pinion +Cross roller guide
Weight: 0,4kg
Noise emission: < 40 dB
Electrical specifications
Communication interface: Modbus RTU(RS 485) , Digital I/O
Nominal voltage: 24 V DC ± 10%
Nominal current: 0.4 A
Peak current: 0.7 A
Ingress protection rating: IP 40
Recommended operating environment : 0~40°C, <85% RH
Der angegebene Betrag ist netto. Die gesetzlich vorgeschriebene Mehrwertsteuer von 19 % wird beim Checkout hinzugefügt. Sie erhalten eine ordentliche Rechnung mit ausgewiesener Mehrwertsteuer.
